Two laminating units, the FOLIANT 520T basic model and
the more powerful FOLIANT 520HP model, function as the basic component of all
configurations and differ only in their maximum operating speed. Both laminating units can
operate independently. In this very basic configuration both units require an operating
staff of two people - one operator for manual feeding and one for manual separation.
Both laminating machines can be easily supplemented with an automatic separator for
separation of laminated sheets. The machines are then operated as semi-automatic lines,
with manual feeding and automatic separation, requiring only one person to operate the
machine. A modular stand and reception unit for storage of laminated sheets can be
supplied as optional accessories.
The more powerful laminating unit, the FOLIANT 52HP model, can be operated as an automatic
laminating line equipped with an automatic sheet feeder. In this configuration the modular
stand and reception unit for storage of laminated sheets are supplied as standard
accessories.
|
Review of the recommended configurations of the
FOLIANT 520 line:
520T laminating unit, manual loading, manual
separation, maximum operating speed 7 m per minute. The machine requires a minimum floor
space of 90 x 80 cm.
520HP laminating unit, manual loading, manual
separation, maximum operating speed 11 m per minute. The machine requires a minimum floor
space of 90 x 80 cm.
The semi-automatic laminating line FOLIANT 520T
consists of the laminating unit FOLIANT 520T and the automatic Separator 520. Manual
feeding, automatic separation, maximum operating speed 7 m per minute. An MT520 modular
stand and RU520 reception unit for storage of laminated sheets are supplied as optional
accessories. The machine requires a minimum floor space of 100 x 250 cm including the
reception unit.
The semi-automatic laminating line FOLIANT 520HP
consists of the FOLIANT 520HP laminating unit and the automatic Separator 520. Manual
feeding, automatic separation, maximum operating speed 11 m per minute. An MT520 modular
stand and RU520 reception unit for storage of laminated sheets are supplied as optional
accessories. The machine requires a minimum floor space of 100 x 250 cm including the
reception unit.
The automatic laminating line FOLIANT 520HP consists
of the FOLIANT 520HP laminating unit, automatic sheet feeder FOLIANT FEEDER 520, and the
automatic Separator 520. Automatic sheet feeder, automatic separation, maximum operating
speed 15 m per minute. An MT520A modular stand and RU520 reception unit for storage of
laminated sheets are supplied as standard accessories. The machine requires a minimum
floor space of 100 x 350 cm.
The machines demonstrate all the advantages of the
FOLIANT project outstanding design, easy handling and operation, single-phase
electrical power supply, low operational cost, easy changing of the processing format, and
independence from the supply of vacuum or compressed air. Laminated sheets do not curl
after lamination and are immediately available for further processing. An integrated film
cutter, for trimming the laminating film to the required width prior to lamination, is
included as a standard accessory. |
Specifications
of single sided laminating machines
Modular range FOLIANT 520 maximum paper sheets 52 x
71 cm
|
|
LAMINATOR
FOLIANT 520T |
|
SEPARATOR
FOLIANT 520 |
FEEDER
FOLIANT FEEDER 520
|
Suitable for format |
B2, B3, B4 |
B2, B3, B4 |
B2, B3, B4 |
B2, B3, B4 |
Max.
working width |
520 mm |
520 mm |
520 mm |
520 mm |
Max.feederīs load
capacity |
- |
- |
- |
30 cm |
Speed control |
0 - 7 m/ min |
0 - 15 m/min |
0 - 15 m/min |
0 - 15 m/ min |
Maximum
performance/hour
(white paper 135 g/m2) |
600 sheets B2 or
1200 sheets B3
|
1300 sheets B2
or
2600 sheets B3
|
1300 sheets B2 or
2600 sheets B3 |
1300 sheets B2
or
2600 sheets B3
|
Temperature control |
80 - 140°C |
80 - 140°C |
80 - 140°C |
80 - 140°C |
Power supply |
220 - 230V, 50 - 60Hz |
220 - 230V, 50 - 60Hz |
220 - 230V, 50 - 60Hz |
220 - 230V, 50 - 60Hz |
Power |
1000 W |
2000 W |
500 W |
1000 W |
Measures (mm) |
900 x 1170 x 800 |
900 x 1170 x 800 |
900 x 960 x 160 |
980 x 1170 x 1000 |
Weight |
85 kg |
95 kg |
75 kg |
75 kg |
Minimum paper size |
250 x 350 mm |
250 x 350 mm |
250 x 350 mm |
250 x 350 mm |
Maximum paper size |
52 x 71 cm |
52 x 71 cm |
52 x 71 cm |
52 x 71 cm |
Infeed belts |
YES |
YES |
|
|
*
Max. speed 15 m/min and maximum performance are given for automatic
feeding only. For manual feeding are both values lower. |
|
